commercial hot model, LS45BDS

Model: LS45BDS, commercial type machine

Brand: Great-Boom

Manufacturer's Warranty: 3-year limited warranty

Beam: Heavy-Duty Formed Steel

Product Type: Horizontal/vertical splitter

Log Stripper: Yes, professional durable heavy-plate

The thermometer on hydraulic oil tank: Available

Level gauge design on hydraulic oil tank: Available

The capacity of the hydraulic oil tank (L): 20

External filtration: 4-stage hydraulic filtration system design

Oil pump: 2-stage, 16GPM, Cast iron concentric pump

Controlling Valve: American-made concentric brand™valve

Ram Force (Tons): 45

Max. Log Size L x W (in.): 24 x 22

Continuous Force (Tons): 40

Engine: Lifan 188FX / 190FX

Engine Displacement (cc): 389 / 429

Gross Torque: 25.0N.m/2600rpm

Low Oil Shutdown: Yes

Wedge: 8 1/2in.H, heavy-duty cast iron knife, electroplated surface

Cycle Time (sec.): 13

Cylinder seals: Halite commercial cylinder, 125°C

Automatic Cylinder Return: Yes

Cylinder: 5" X 24" clevis type, 1.75" rod

Pump: 16 GPM (Deli)

Max. PSI: 3,500

Oil Reservoir (gal.): 5.3

Fuel Capacity (gal.): 1.72

Hoses: High-pressure w/wire braid, 40Mpa capacity

Log Cradle: Yes

Log Table: Yes

Log Lift: No

Jack Stand: Yes, 2000 lbs

Brake wheel (in.) (Front): 8”, industrial standard, 2ton pressure capacity

Ball Coupler (in.): 2”, Max payload 1500kgs

Tire Size: DOT, tubeless, 650 x 8.0" Highway Rated

Lights: No

Fenders: Yes

Tow cable: Yes

Pre-assembled: Assembly required

Package: 10mm / 12mm thickness wooden packing, no fumigation, export type

Machine Dimensions : L x W x H (in.)90.55” x 47.64” x 48.82” / (230 X 119 X 124CM)

Package Dimensions : L x W x H (in.)83.47” x 22.44” x 25” / (212 x 57 x 63.5 cm)

Package Material: Fully enclosed wooden box, suitable for export, no fumigation

Ship Weight: 691.0 lbs (313.43KGS)
