LS24T/30T/40T/50T-610mm-CTM

Model NO.: LS24T30T40T-CTM Log Splitter

Price: USD 400.00-750.00 / pieces

Delivery: FOB

Min order: 20 pieces

Accept Min order: Yes

Supply Ability: 200 pieces / Month

0.00
0.00


Model NO.: LS24T30T40T-CTM Log Splitter

Price: USD 400.00-750.00 / pieces

Delivery: FOB

Min order: 20 pieces

Accept Min order: Yes

Supply Ability: 200 pieces / Month

Brand: GREAT-BOOM

Model: LS24T/30T/40T-610mm-CTM

Engine: 6.5 horsepower, 4 stroke, OHV, air cooled

             9.0 horsepower, 4 stroke, OHV, air cooled

             13.0 horsepower, 4 stroke, OHV, air cooled

Engine Brand: LIFAN, KOHLER, B&S

Start: manual (recoil) start

Hydraulic Cylinder Size: 114.30mm diameter x 610mmstroke;

                                        127.00mm diameter x 610mmstroke

                                        140.00mm diameter x 610mmstroke

Oil Capacity: 30.5 liters

Gear Pump: 2 stage 11GPM flow;

2 stage 16GPM flow

2 stage 16GPM flow

Valve: automatic return control valve with safety release function

Maximum Splitting Force: 24Ton, 30Ton, 40Ton

Wedge Height: 8 inch (200mm) cast wedge material

Split and Return Cycle Time: 13 seconds

                                               13 second

                                               14 second

Maximum Log Length: 24 inch (610mm)

Working Position: horizontal & vertical

Wheels and Tires: 16 inch pneumatic x 4.8 inch tubeless

Mudguard: with

Coupler:50mm cast steel with safety chains

Maximum Recommended Towing Speed: 40 km/h

Package Diameter: 210cmx51cmx45cm

Package Weight: 233KGS; 246KGS; 257KGS

Warranty: 6 months

If Iron Frame Package: 40PCS / 40PKGS / 20GP; 88PCS / 88PKGS / 40HQ

Product Description

40Ton Lifan Power engine Manual / Hydraulic Log Splitters with CE

TECHNICAL SPECIFICATION

Model

LS24T30T40T-CTM

Description

Gasoline engine driven, horizontal or vertical,Recoil or Electric

Gasoline power

6.5HP

9.0HP

13.0HP

Diesel power

8.0HP

8.0HP

11.0HP

Max. split force

24tons

30tons

40Tons

Max split size

615mm

Hydraulic oil

30.5 Liter

Oil cylinder diameter

4.0inch

4.5inch

5.0inch

Travel time

13seconds

Brand of Petrol engine

Lifan,Honda,Kohler,B&Sor other

Brand of diesel engine

H-Power

Starting System

Recoil or Electric

Packing dimensions

210*54*54

N.W./ G.W.

218/233kgs

231/246kgs

242/257Kgs

Packing Method

Iron Frame & Wrapping Film or Wooden Pallet (optional)

Container Qua

40pcs. for 20'FCL 80pcs.for40'HQ

Warranty

24 months since B/L date
